Send Inquiry15 KVA Diesel Generator
Price 29543.00 INR/ Unit
MOQ : 1 Unit
15 KVA Diesel Generator Specification
- Fuel Consumption
- 3.80 Liter/Hour (L/hr)
- Bore *Stroke
- BORE 100MM STOKE 125MM
- Engine Type
- Air-cooled
- Dimension (L*W*H)
- 1800 Centimeter (cm)
- Fuel Tank Capacity
- 80 Liter (L)
- Insulation
- CLASS-H
- Poles Number
- Silent diesel genrator
- Alternator
- Single Bearing Brushless
- Engine Model
- 322ES
- Protection Class
- A1
- Product Type
- Generator
- Output Type
- Eicher TMTL Diesel Generators
- Rated Power
- 15KVA
- Rated Voltage
- 415 Volt (V)
- Starting Type
- Electric Start
- Rated Frequency
- 1500 Hertz (HZ)
- Power Range
- 25.1BPH
- Color
- Red
- Cooling System
- Air-cooled
- Noise Level
- 6570 db
- Phase
- Three Phase
- Speed
- 1500 RPM
- Weight
- 900 Kilograms (kg)
- Warranty
- 2year
15 KVA Diesel Generator Trade Information
- Minimum Order Quantity
- 1 Unit
- FOB Port
- NO
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID)
- Supply Ability
- 5000 Units Per Month
- Delivery Time
- 1 Week
- Sample Available
- No
- Packaging Details
- Open Box Plastic Raping
- Main Domestic Market
- Gujarat
- Certifications
- Genset Rating kVA 15 Duty Prime / Standby Prime Engine manufacturer - TAFE Motors and Tractors Limited Engine brand - Eicher Engines Engine model - 322 ES Number of cylinders nos. 2 Aspiration - Naturally Aspirated Engine power (gross) BHP 25.1 Engine power (net) BHP 23.8 Rated speed & frequency RPM /Hz 1500/ 50 Hz Stroke mm 125 Bore mm 100 Displacement cc 1963 Compression ratio - 17 : 1 Reference standard - BS: 5514, ISO: 3046, IS: 10000, ISO: 8528 Type of governer - Mechanical Fuel injection System / FIP Type - Block Type PFR-2K Class of Governing - A1 Air cleaner - Dry Type of cooling - Air Cooled Fuel Tank Capacity L 100 Fuel Consumption at 100% load* L/h 3.80 Fuel Consumption at 75% load* L/h 3.00 Fuel Consumption at 50% load* L/h 2.20 Lube oil Sump capacity (with filters) L 8.0 Lube Oil Consumption % of FC < 0.15% of FC Coolant Capacity - TOTAL L Not Applicable Coolant Capacity - Radiator L Not Applicable Phase - 1 Phase-2 wire / 3Phase-4 wire Voltage VAC 230/ 240, 415 Voltage Regulation % of Rated voltage +/- 1% Power Factor Lag 0.8 Power Alternator Type - Single Bearing, Brushless Insulation - Class-H Make - Leroy Somer/ KEC/ CGL/ Meccalte / Stamford Starting System - Electric Battery Volts, Ah 12 Volts, 88 / 90 Ah Battery Make - Exide / AMCO / Amaron Silencer Location & Type Internal / Residential Acoustic Insulation Type - PU FR- Acoustic Foam Acoustic Insulation Thickness mm 40 DG Set Dimensions ( L X B X H) mm 1700 x 900 x 1250 Wet Weight (Engine) (Approx)+ kg 370 Weight of DG Set (Approx)+ kg 950
About 15 KVA Diesel Generator
| kVA | 15 | |
| Duty | Prime / Standby | Prime |
| Engine manufacturer | - | TAFE Motors and Tractors Limited |
| Engine brand | - | Eicher Engines |
| Engine model | - | 322 ES |
| Number of cylinders | nos. | 2 |
| Aspiration | - | Naturally Aspirated |
| Engine power (gross) | BHP | 25.1 |
| Engine power (net) | BHP | 23.8 |
| Rated speed & frequency | RPM /Hz | 1500/ 50 Hz |
| Stroke | mm | 125 |
| Bore | mm | 100 |
| Displacement | cc | 1963 |
| Compression ratio | - | 17 : 1 |
| Reference standard | - | BS: 5514, ISO: 3046, IS: 10000, ISO: 8528 |
| Type of governer | - | Mechanical |
| Fuel injection System / FIP Type | - | Block Type PFR-2K |
| Class of Governing | - | A1 |
| Air cleaner | - | Dry |
| Type of cooling | - | Air Cooled |
| Fuel Tank Capacity | L | 100 |
| Fuel Consumption at 100% load* | L/h | 3.80 |
| Fuel Consumption at 75% load* | L/h | 3.00 |
| Fuel Consumption at 50% load* | L/h | 2.20 |
| Lube oil Sump capacity (with filters) | L | 8.0 |
| Lube Oil Consumption | % of FC | < 0.15% of FC |
| Coolant Capacity - TOTAL | L | Not Applicable |
| Coolant Capacity - Radiator | L | Not Applicable |
| Phase | - | 1 Phase-2 wire / 3Phase-4 wire |
| Voltage | VAC | 230/ 240, 415 |
| Voltage Regulation | % of Rated voltage | +/- 1% |
| Power Factor | Lag | 0.8 |
| Power Alternator Type | - | Single Bearing, Brushless |
| Insulation | - | Class-H |
| Make | - | Leroy Somer/ KEC/ CGL/ Meccalte / Stamford |
| Starting System | - | Electric |
| Battery | Volts, Ah | 12 Volts, 88 / 90 Ah |
| Battery Make | - | Exide / AMCO / Amaron |
| Silencer Location & Type | Internal / Residential | |
| Acoustic Insulation Type | - | PU FR- Acoustic Foam |
| Acoustic Insulation Thickness | mm | 40 |
| DG Set Dimensions ( L X B X H) | mm | 1700 x 900 x 1250 |
| Wet Weight (Engine) (Approx)+ | kg | 370 |
| Weight of DG Set (Approx)+ | kg | 950 |
Description:
- In wide range of products we have established our plant to produce genset upto 320KVA with modern techniques and experience manpowers. The Genset is supplied with Mahindra Powerol engine and alternator of reputed make Crompton greave/Leroy somar.
- The Mahindra powerol Gensets are compact in design, robust & low on vibration. This Genset has the smallest footprint to the other identical rating, making the Genset apt even the roof mounting.
- Each and every powerol DG set complies with the most stringent noise and emission norms stipulated by central pollution board of India (CPCB).
Other Details:
- Most fuel efficient in its class.
- Zero leak engines.
- A-1class Governing-Safe Guards your expensive equipment.
- Electronic Governor/Actuators fitted on all engines of 5 to 125 KVA DG Sets.
- Wet replaceable liners for extended engine life.
- Easily serviceable and low on maintenance cost.
- Structural cylinder block design to easily withstand heavy duty operations.
FAQs of 15 KVA Diesel Generator:
Q: What is the noise level of the 15 KVA Diesel Generator?
A: The noise level of the 15 KVA Diesel Generator is 65-70 decibels.Q: What is the fuel tank capacity of the generator?
A: The fuel tank capacity of the generator is 80 liters.Q: What is the warranty period for the 15 KVA Diesel Generator?
A: The warranty period for the generator is 2 years.Q: What is the starting type of the 15 KVA Diesel Generator?
A: The starting type of the generator is electric start.Q: What is the rated voltage of the generator?
A: The rated voltage of the generator is 415 volts.Q: What is the weight of the 15 KVA Diesel Generator?
A: The weight of the generator is 900 kilograms.Q: What is the power range of the generator in terms of Brake Horsepower (BHP)?
A: The power range of the generator is 25.1 BHP.
